From microplate instrumentation to confocal imaging to liquid handling solutions and more, contact a sales representative to get more details.
The BioTek BioSpa live cell analysis system offers unique benefits for a wide variety of live cell imaging applications in up to 8 microplates or other labware. For Research Use Only. Not for use in diagnostic procedures.
Height (Metric) | 48 cm |
---|---|
Depth (English) | 20.1 in. |
Width (English) | 27.2 in. |
Product Type | Automated Microplate Incubator |
Depth (Metric) | 51 cm |
Humidity | 80 to 95% |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Width (Metric) | 69 cm |
Operating Temperature Range (Metric) | Ambient to 45°C |
Height (English) | 18.9 in. |
Epoch microplate spectrophotometer has monochromator-based optics, for a filter-free, wide wavelength range for UV-Vis absorbance measurements. For Research Use Only. Not for use in diagnostic procedures.
Height (Metric) | 19.6 cm |
---|---|
Cuvette Size | 0.5 mm |
Width (English) | 12 in. |
Absorbance Range | 200 to 999 nm, 1 nm increments |
Light Source | Xenon Flash Lamp |
Width (Metric) | 30.5 cm |
Accuracy | ±2 nm |
Precision | ±0.2 nm |
Product Type | Microplate Reader |
Voltage | 100/240 V |
Bandwidth | 5 nm |
Weight (English) | <15 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Hertz | 50/60 Hz |
Wavelength Range | 200 to 999 nm |
Weight (Metric) | 6.8 kg |
Resolution | 0.0001 OD |
Height (English) | 7.7 in. |
Plate Type | 6 to 384-well Plates |
Automatically creates reproducible scratch wounds in cell monolayers grown in 24- or 96-well microplates for cell migration and invasion studies.
The BioTek 50 TS washer offers excellent microplate washing performance. For In Vitro Diagnostic Use.
Wash Volume | 25 to 3000 μL/well |
---|---|
Connections | USB (1) |
Fluid Delivery Type | One positive displacement syringe drive |
Automation Interface | 4.3 in. Color LCD Touch Screen Display |
Flow Rate | 150 to 1000 μL/well/sec. (manifold dependent) |
Type | Microplate Washer |
Bottles | Optional (2 to 4 L) |
Wash Cycles | 1 to 10 |
Soak Time | Programmable in minutes and seconds, up to 30 min. |
Weight (English) | 22 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Display | 4.3 in. LCD Color Touch Screen |
Weight (Metric) | 9.8 kg |
Plate Type | 24-, 96-, 384-well Plates (96- and 384-well: Standard and Low Profile Plates, Solid and Filter Bottom (Option), 24-well Plates with 4-well Manifold) |
The BioTek 405 LS washer has a well earned reputation as an economical plate washer that offers excellent performance and reliability.
Height (Metric) | 25.4 cm |
---|---|
Depth (English) | 17 in. |
Width (English) | 14 in. |
Width (Metric) | 35.6 cm |
Flow Rate | High to Low Flow; Optimized rates for cell assays |
Type | Microplate Washer |
Bottles | Optional (4 or 10 L) |
Washing Speed | 96-wells: 300 μL/well, 3 cycles: <30 s; 384-wells: 100 μL/well, 3 cycles: <80 s; 384-wells: 400 μL/well, 1 cycle: <20 s |
Dispense Volume | 25 to 3000 μL/well |
Precision | <3% CV: 300 μL/well (96-well washing); <4% CV: 80 μL/well (384-well washing) |
Depth (Metric) | 43.2 cm |
Wash Cycles | 1 to 250 |
Voltage | 100/240 V |
Humidity | 10 to 85%, noncondensing |
Soak Time | Programmable in minutes and seconds, up to 60 min. |
Increments | 1 μL |
Frequency | 50/60 Hz |
Residual Volume | <2 μL/well (96- and 384-well plates), 96-tube manifold for 96 wells, 192-tube for 384 wells |
Weight (English) | With internal buffer switching - 36 lb.; Without - 30 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Height (English) | 10 in. |
Weight (Metric) | With internal buffer switching - 16.5 kg; Without - 13.5 kg |
Plate Type | 96- and 384-well, Low Profile and Standard, Solid and Filter Bottom (Pore Sizes 0.45 to 1.2 μm) Plates |
MultiFlo FX is an automated multi-mode reagent dispenser for 6- to 1536-well microplates. For In Vitro Diagnostic Use.
Height (Metric) | 20.3 cm |
---|---|
Speed | 96 wells, 5 μL cass, 10 μL/ well: 3 s, 96 wells, 5 μL cass, 20 μL/ well: 3.5 s, 384 wells, 5 μL cass, 5 μL/ well: 6.5 s, 384 wells, 10 μL cass, 10 μL/ well: 8 s, 384 wells, 1 μL cass, 1 μL/ well: 6 s, 1536 wells, 1 μL cass, 1 μL/ well: 21 s |
Electrical Requirements | 90 W max. |
Depth (English) | 11.8 in. |
Width (English) | 17.2 in. |
For Use With (Application) | Primary/secondary screening assays, compound storage, genomics and proteomics research, ELISA, cell based washing, fixing, staining, volume or concentration normalization |
Width (Metric) | 43.5 cm |
Accuracy | ±5% at 1 μL, ±2.0% at 5 μL, ±2.0% at 10 μL |
Precision | <5% CV at 1 μL, <2.5% CV at 5 μL, <2.0% CV at 10 μL |
For Use With (Equipment) | BioStack and third party automation compatible; BioSpa 8 Automated Incubator compatible |
Product Type | Microplate Dispenser |
Depth (Metric) | 29.2 cm |
Voltage | 100/240 V |
Weight (English) | 14.3 lb. |
Software | LHC2 Software; LHC2 Secure for 21 CFR Part 11 compliance (option); SiLA Compliant driver (option) |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Interface | Color touch screen; Create, edit or run multiple protocols onboard |
Weight (Metric) | 6.5 kg |
Height (English) | 8 in. |
Plate Type | Dispensing (peri pump and syringe): 96-, 384- and 1536-well standard, deep and PCR plates; 6-. 12-, 24- and 48-well plates (dispense tip configurable); Washing: 96-. 384-well standard plates; 6-, 12-, 24-,and 48-well plates (with compatible manifold configuration) |
BioTek Synergy Neo2 multi-mode microplate reader features patented Hybrid Technology, with independent optical paths that ensure excellent performance in all detection modes. For In Vitro Diagnostic Use.
Height (Metric) | 41 cm |
---|---|
Depth (English) | 20.7 in. |
Width (English) | 15.4 in. |
Shaking | Linear, Orbital, Double Orbital |
Software Type | Gen5 Data Analysis Software,Gen5 Secure for 21 CFR Part 11 compliance (option) |
Absorbance Range | 230 to 999 nm, 1 nm increments |
Incubator Temperature | ±0.2°C at 37°C |
Light Source | Xenon Flash |
For Use With (Application) | HTS, biomarker, nucleic acid, protein quantification, rapid kinetics, HTRF, SNP, TR FRET, BRET, Cytokines, ELISA, FP |
Width (Metric) | 39 cm |
Dynamic Range | 0 to 4 OD |
Detector Type | Photodiode,Fluorescence/Alpha: Dual PMT or Single PMT (option) |
Accuracy | Monochromator: ±2 nm; <1% at 2.0 OD, <3% at 3.0 OD |
Dispense Volume | 5 to 1000 μL, 1 μL increments |
Product Type | Multi-Mode Microplate Reader |
Linearity | ≤1% from 0 to 3 OD |
Depth (Metric) | 52.5 cm |
Weight (English) | 78 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Power Consumption | 250 W max. |
CO2 Concentration Range | 0 to 20% |
Weight (Metric) | 35 kg |
Resolution | 0.0001 OD |
Height (English) | 16.1 in. |
The BioTek Synergy HTX is a compact, economical multi-mode reader for 6- to 384-well microplates and Take3 microvolume plates. For Research Use Only. Not for use in diagnostic procedures.
Width (English) | 16 in. |
---|---|
Shaking | Linear, Orbital |
Software Type | Gen5 Microplate Reader and Imager Software,Gen5 Secure for 21 CFR Part 11 compliance (option) |
Absorbance Range | 200 to 999 nm, 1 nm increments |
Light Source | Xenon Flash,Tungsten Halogen (Alpha Detection/Fluorescence Intensity) |
Width (Metric) | 40.6 cm |
USB Connections | 2 |
Detector Type | Photodiode,PMT |
Reading Options | End Point,Kinetic,Spectral Scanning,Well Area Scanning |
Accuracy | Absorbance: ±2 nm; <1% at 2.0 OD, <3% at 3.0 OD; Dispense: ±1 μL or 2% |
No. of Dispensers | 2 Syringe Pumps |
Voltage | 100/240 V |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Weight (Metric) | 18 kg |
Height (English) | 10 in. |
Height (Metric) | 25.4 cm |
Depth (English) | 15 in. |
Incubator Temperature | 4-Zone Incubation to 50°C with Condensation Control (±0.2°C at 37°C) |
Dynamic Range | Absorbance: 0 to 4 OD; Fluorescence Intensity/Luminesence: >6 decades |
Product Type | Multi-Mode Microplate Reader |
Depth (Metric) | 38 cm |
Measurement Speed | 31 sec. (96 wells), 80 sec. (384 wells) |
Frequency | 50/60 Hz |
Weight (English) | 40 lb. |
Compatibility | BioStack and Third Party Automation Compatible |
Plate Type | 6- to 384-well Plates |
The 406 FX IVD is a compact instrument offering fast, full plate washing along with up to six reagent dispensers, making it suitable for more complex liquid handling requirements in the clinical laboratory. For In Vitro Diagnostic Use.
The BioTek 405 LS washer has a well earned reputation as an economical plate washer that offers excellent performance and reliability. For In Vitro Diagnostic Use.
Height (Metric) | 25.4 cm |
---|---|
Depth (English) | 17 in. |
Width (English) | 14 in. |
Width (Metric) | 35.6 cm |
Flow Rate | High to Low Flow; Optimized rates for cell assays |
Type | Microplate Washer |
Bottles | Optional (4 or 10 L) |
Washing Speed | 96-wells: 300 μL/well, 3 cycles: <30 s; 384-wells: 100 μL/well, 3 cycles: <80 s; 384-wells: 400 μL/well, 1 cycle: <20 s |
Dispense Volume | 25 to 3000 μL/well |
Precision | <3% CV: 300 μL/well (96-well washing); <4% CV: 80 μL/well (384-well washing) |
Depth (Metric) | 43.2 cm |
Wash Cycles | 1 to 250 |
Voltage | 100/240 V |
Humidity | 10 to 85%, noncondensing |
Soak Time | Programmable in minutes and seconds, up to 60 min. |
Increments | 1 μL |
Frequency | 50/60 Hz |
Weight (English) | With internal buffer switching - 36 lb.; Without - 30 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Height (English) | 10 in. |
Weight (Metric) | With internal buffer switching - 16.5 kg; Without - 13.5 kg |
Plate Type | 96- and 384-well, Low Profile and Standard, Solid and Filter Bottom (Pore Sizes 0.45 to 1.2 μm) Plates |
The BioTek 405 TS washer has an excellent reputation in life science research for outstanding results in many applications.
Wash Volume | 25 to 3000 μL/well |
---|---|
Connections | USB (2) |
Height (Metric) | 25.4 cm |
Depth (English) | 17 in. |
Fluid Delivery Type | Internal positive displacement pump |
Automation Interface | High Resolution LED Backlit Touch Screen |
Width (English) | 14 in. |
Width (Metric) | 35.6 cm |
Type | Microplate Washer |
Bottles | Optional (4 or 10 L) |
Dispense Volume | 25 to 3000 μL/well (192-pin manifold); 50 to 3000 μL/well (96-pin manifold) |
Depth (Metric) | 43.2 cm |
Wash Cycles | 1 to 250 |
Voltage | 100/240 V |
Soak Time | Programmable in minutes and seconds, up to 60 min. |
Frequency | 50/60 Hz |
Residual Volume | ≤2 μL/well |
Weight (English) | With internal buffer switching - 36 lb.; Without - 30 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Height (English) | 10 in. |
Display | LED |
Weight (Metric) | With internal buffer switching - 16.5 kg; Without - 13.5 kg |
Plate Type | 96- and 384-well, Low Profile and Standard, Solid and Filter Bottom (Option) Plates |
The 406 FX is a compact instrument offering fast, full plate washing along with up to six reagent dispensers. For Research Use Only.
The BioTek EL406 washer dispenser is a compact instrument offering fast, full plate washing along with three reagent dispensers.
Depth (English) | 18 in. |
---|---|
Width (English) | 16.5 in. |
Width (Metric) | 42 cm |
Flow Rate | High to Low Flow; Optimized rates for cell assays |
Type | Microplate Washer/Dispenser |
Accuracy | ±3%; Dispensing: ±1 μL at 5 μL, +1 μL at 20 μL, ±1% at 100 μL |
Bottles | Optional (1 or 2 L) |
Washing Speed | 96 wells: 300 μL/well, 96-tube manifold: 13 s; 384 wells: 100 μL/well, 192-tube manifold: 17 s; 1536 wells: 10 μL/wells, two 32-tube manifolds: 36 s |
Dispense Volume | 500 nL to 3000 μL/well |
Precision | Wash: <3% CV (model dependent); Dispense (Syringe Pump): ≤5% CV at 5 μL, ≤2.5% CV at 20 μL, ≤1% CV at 100 μL |
Depth (Metric) | 46 cm |
Wash Cycles | 1 to 250 |
Voltage | 100/240 V |
Soak Time | Programmable in minutes and seconds, up to 60 min. |
Increments | 1 μL |
Frequency | 50/60 Hz |
Residual Volume | ≤2 μL/well |
Weight (English) | 32 lb. |
Certifications/Compliance | CE and TUV marked. RoHS compliant. |
Weight (Metric) | 14.5 kg |
Plate Type | 96-, 384- and 1536-well; Low profile and standard height; Solid and filter bottom (option) plates |
For use with PowerWave HT and PowerWave XS microplate spectrophotometers.
